LPTC series PTC thermistors

Features
1. LPTC series in the form of axial glass encapsulated form.
2. As the construction material is mainly semiconductor monocrystalline silicon, also called silicon thermistor.
3. Resistance increases with the temperature rises in linearity, also called linear PTC thermistor.
4. Dissipation factor:2.5~5mW/℃
5. Maximum operating current:Iopr=1.0mA
6. Stability: annual diversification rate≤0.01℃/per year.
7. Temperature coefficient:α25/50≥0.7%/℃
8. Rated power:10mW
9. Operating temperature range:-50~+150℃
10. Small dimension, tightness, convenient for automatic installation.
11. Glass encapsulated, can operate in high temperature and moisture environment.

Application
  1. Automobile temperature inspection and control.
  2. Home appliance temperature inspection and compensation.
  3. Precision circuit and crystal oscillator temperature compensation.
  4. Micro motor timing control.
  5. Medical equipment temperature inspection and control.

Outlook and Dimension(Unit:mm)

LPTC Data Sheet and R-T Table
